| Part # | 8MEGATECH1000xCL15 | ||
| Continuous Operating Temperature Range | -40°F to +300°F | ||
| Minimum Bend Radius (mm) | 90 | ||
| Hose Inside Diameter (in) | 0.50 | ||
| Inside Diameter (in) | 1/2 | ||
| Temperature Range | -40/150 | ||
| Outside Diameter (mm) | 20.30 | ||
| Coupling Recommendation | (See Crimp Data Manual 428-7365 or E-Crimp), MegaCrimp® Couplings (G25) Section G | ||
| Cover | TEXTILE | ||
| Tube | GTS (Gates Technical Spec.) black tube specifically compounded for temperature and chemical resistance (CPE - Type J). See Hose Stock Characteristics. | ||
| Construction: Tube | CPE | ||
| Meets These Agency Specifications | DOT - Department of Transportation; USA, FMVSS - Federal Motor Vehicle Safety Std. USA, SAE - Society of Automotive Engineers | ||
| Packaging | T |
| Product # | 4657-02505 | ||
| Minimum Bend Radius (in) | 3.50 | ||
| Min. Burst Pressure (psi) | 4,000 | ||
| Hose Outside Diameter (in) | 0.80 | ||
| Inside Diameter (mm) | 12 | ||
| Outside Diameter (in) | 0.80 | ||
| Specifications | Minimum Burst Pressure (Bar): 280 | ||
| Use | Fleet | ||
| Reinforcement | One braid of high-tensile steel wire. | ||
| Construction: Reinforcement | 1WB | ||
| Standard Industry Specification | SAE J1402 | ||
| Weight (lbs.) | 11.81 | ||
| UPC | 072053549348 |
