| ras max - Max shaft & housing fillet radius | 1,5 mm | ||
| da min - Min shoulder diameter IR | 163 mm | ||
| FTF - Characteristic cage frequency | 0,5 Hz | ||
| BPFO - Characteristic outer ring frequency | 10 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Nlim - Grease lubrication limit speed | 430 tr/min | ||
| Ca - Dynamic axial load rating | 335 kN | ||
| Ea - Rollers reference outer diameter | 163 mm | ||
| Bearing ring (inner ring) WS | WS89320 | ||
| rs - Min fillet radius | 1,5 mm | ||
| D - Outside diameter of support washer OR - GS | 170 mm |
| Db max - Max OR shoulder diameter | 110 mm | ||
| BSF - Characteristic rolling element frequency | 10,523 Hz | ||
| BPFI - Characteristic inner ring frequency | 10 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Oil lubrication limit speed | 1700 tr/min | ||
| C0a - Static axial load rating | 1370 kN | ||
| Eb - Rollers reference inner diameter | 110,6 mm | ||
| Bearing ring (outer ring) GS | GS89320 | ||
| Cage assembly reference | K89320L1 | ||
| B - Ring thickness | 14,5 mm | ||
| Brand | NTN |
