| coil code | 9,151 | ||
| Flow direction | determined | ||
| fluid temperature temperature celsius min to max range | -10 ... 90 °c | ||
| kv value flow cubicmeterperhour | 3.4 m³/h | ||
| operating pressure psi pressure psi min to max range | 0 ... 145 psi | ||
| operating temperature temperature celsius min to max range | -10 ... 50 °c | ||
| Port size | g1/2 | ||
| range | 82,590 | ||
| valve operation | 2/2 |
| Electrical connection | din en 175301-803 form a | ||
| fluid temperature imperial temperature fahrenheit min to max range | 14 ... 194 °f | ||
| inner parts | pvdf | ||
| operating pressure pressure bar min to max range | 0 ... 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | 14 ... 122 °f | ||
| orifice metric | 12 mm | ||
| Protection class | en 60529 ip65 | ||
| seat seal | fpm |
