| airflow vacuum nlmin | 23326 nl/min | ||
| body | brass | ||
| fluid temperature temperature celsius min to max range | -10 ... 60 °c | ||
| kv value flow cubicmeterperhour | 53 m³/h | ||
| operating pressure pressure bar min to max range | 0 ... 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | 14 ... 356 °f | ||
| orifice metric | 50 mm | ||
| range | 82,180 | ||
| valve operation | 2/2 |
| ambient temperature temperature celsius min to max range | -10 ... 60 °c | ||
| Flow direction | fixed | ||
| inner parts | brass | ||
| maximum fluid temperature temperature celsius | 180 °c | ||
| operating pressure psi pressure psi min to max range | 0 ... 145 psi | ||
| operating temperature temperature celsius min to max range | -10 ... 180 °c | ||
| Port size | g2 | ||
| seat seal | ptfe |
