| Rip diameter shaft washer | d1 | 68 | mm |
| Minimum chamfer dimension | rmin | 1 | mm |
| Maximum recess radius | ra max | 1 | mm |
| Minimum diameter shaft shoulder | da min | 66 | mm |
| Maximum diameter of housing shoulder | Da max | 43 | mm |
| Reference speed | nϑr | 1,820 | |
| Fatigue load limit, axial | Cua | 23,700 | |
| Basic dynamic load rating, axial | Ca | 107,000 | |
| Outside diameter | D | 68 | mm |
| Limiting speed | nG | 5,200 | |
| Basic static load rating, axial | C0a | 265,000 | |
| Height | T | 19 | mm |
| Bore diameter | d | 40 | mm |
