| protection class measurement device (ip) | ip65 | ||
| electrical connection 1 material category | plastics | ||
| electrical connection 1 number of contacts | 3 pce | ||
| electrical connection 1 type | cable with open end | ||
| construction device | compact | ||
| Type | 8,031 | ||
| continuous measurement | yes | ||
| output 1 digital transistor connection pnp | yes | ||
| digital output 1 transistor contactless | 0,01 a | ||
| medium-contacting parts seal material | fkm (fluor rubber) | ||
| temperature environment max | 80 °c | ||
| temperature medium max | 80 °c | ||
| pressure max sensors | 10 bar | ||
| electronics body material | pom | ||
| sensor body material | pom | ||
| screws material | stainless steel | ||
| dc voltage min | 5 v | ||
| port connection material category | plastics | ||
| port connection 2 thread type | g | ||
| port connection 1 thread type | g | ||
| port connection 1 type | outer thread | ||
| max measured value of volume flow rate | 100 | ||
| precision of volume flow rate in relation to reading | 2 % | ||
| dynamic viscosity max. | 10 cp | ||
| fluidic port connection number | 2 | ||
| bearing material category | plastics | ||
| paddle wheel type | magnetic | ||
| paddle wheel material | pom | ||
| Customscode | 90261021 |
| electrical connection 1 material | pvc (polyvinyl chloride) | ||
| electrical connection 1 wire length | 1.000 mm | ||
| electrical connection 1 quantity | 1 pce | ||
| installation length | 77 mm | ||
| product sub-group | flow rate | ||
| parametrisation fixed | yes | ||
| diameter measuring tube (dn) | 6 mm | ||
| output 1 digital transistor connection npn | yes | ||
| output 1 digital type | transistor | ||
| seal housing/cover material | fkm | ||
| temperature environment min | 0 °c | ||
| temperature medium min | 0 °c | ||
| measuring pipe material | pom (polyoxymethylene) | ||
| electronics body material category | plastics | ||
| cover material | pom | ||
| dc voltage max | 24 v | ||
| port connection material | pom | ||
| port connection 2 thread marking | 1/4 | ||
| port connection 2 type | outer thread | ||
| port connection 1 thread marking | 1/4 | ||
| measured value unit | l/h | ||
| min measured value of volume flow rate | 10 | ||
| flow rate (volume) | yes | ||
| dynamic viscosity min. | 1 cp | ||
| bearing material | pom (polyoxymethylene) | ||
| paddle wheel axle material | coated stainless steel | ||
| paddle wheel measuring principle detection | hall | ||
| Sensor type | paddle wheel |
