| motors | aazadaa0000a0b 82.6 ccr motor 15t spline rear po | ||
| output shaft | ad : 15 tooth 16/32 spline with snap ring groove, shaft ext 46 [1.81] | ||
| drain port size & location | a : .5625-18 unf-2b o-ring port size -6 accepts fittings for sae j1926 - horizontal top rear of unit | ||
| special features | 00 : none | ||
| identification | 0 : standard |
| code title | aaz : 82.6 cm3/r [5.04 in3/r] fixed displacement motor | ||
| main ports size & location | a : 1.0625-12 un-2b o-ring port size -12 accepts fittings for sae j1926 - (rear) | ||
| auxiliary mounting features (rear) | 0 : none | ||
| paint | 0a : primer per spec 209-13a | ||
| design code | b : bearing upgrade |
