| pumps | achrabb00de2nn0m00c000b0 00d | ||
| input shaft | a : 15 tooth 16/32 external, dia 24.98 [.984], shaft ext 46 [1.81] | ||
| auxiliary mounting features (rear) | b : [2-bolt b] sae flange series 101-2 | ||
| charge pump relief setting and routing | 0 : no charge pump | ||
| Additional functions | 0 : no additional functions | ||
| control servo orifice (s1 and s2) | 0 : no control servo orifice | ||
| paint | 0b : black per spec 209-13b | ||
| identification | 0 : standard | ||
| drain port size and location | e | ||
| relief valve setting for main port a | n | ||
| control assembly | m0 | ||
| code title | ach |
| input shaft rotation | r : right hand rotation (cw) | ||
| output shaft | b : 41 tooth 48/96 external, dia 22.22 [.875], accepts shaft ext 24.4 [.96] | ||
| charge pump | 0 : no charge pump | ||
| auxiliary port size and location | d : .750-16 unf-2b sae o-ring port - left (c1) & right (c2) sides (housing), left side plugged | ||
| destroke valve | 0 : not required | ||
| special control options | 0 : no special control options | ||
| special features | 00 : no special features | ||
| design code | d : d | ||
| main ports size and location | 2 | ||
| relief valve setting for main port b | n | ||
| control supply orifice (p) | c |
