| Bore diameter | d | 65 | mm |
| Width | B | 33 | mm |
| Basic static load rating, radial | C0r | 60,000 | |
| Fatigue load limit, radial | Cur | 4,050 |
| Outside diameter | D | 140 | mm |
| Basic dynamic load rating, radial | Cr | 100,000 | |
| Limiting speed | nG | 3,050 |
| Shoulder diameter inner ring | d1 | 88.30 | mm |
| Minimum chamfer dimension | rmin | 2.10 | mm |
| Caliber diameter outer ring | D2 | 122.20 | mm |
| Maximum fillet radius | ra max | 2.10 | mm |
| Minimum diameter shaft shoulder | da min | 77 | mm |
| Maximum diameter of housing shoulder | Da max | 128 | mm |
