| Brand | NTN | ||
| Radial clearance class | C3 | ||
| C0 - Static load | 2,39 kN | ||
| f0 - Coefficient | 13.20 | ||
| Tmin - Min operating temperature | -25 °C | ||
| BPFO - Characteristic outer ring frequency | 3,071 Hz | ||
| FTF - Characteristic cage frequency | 0,384 Hz | ||
| da min - Min shoulder diameter IR | 14 mm | ||
| Da max - Max shoulder diameter OR | 26 mm |
| rs - Min fillet radius | 0,6 mm | ||
| C - Dynamic load | 5,65 kN | ||
| Cu - Fatigue limit load | 0,182 kN | ||
| Nlim - Grease lubrication limit speed | 21000 tr/min | ||
| Tmax - Max operating temperature | 120 °C | ||
| BPFI - Characteristic inner ring frequency | 4,929 Hz | ||
| BSF - Characteristic rolling element frequency | 4,072 Hz | ||
| da max - Max shoulder diameter IR | 16 mm | ||
| ra max - Max shaft & housing fillet radius | 0,6 mm |
