| Bore diameter | d | 35 | mm |
| Width | B | 14 | mm |
| Recess diameter | D2 | ≈55.61 | |
| Width of snap ring groove | b | 1.90 | mm |
| Bottom radius of snap ring groove | r0 | max.0.6 |
| Outside diameter | d2 | 62 | mm |
| Shoulder diameter | d1 | ≈43.75 | |
| Diameter of snap ring groove | D3 | 59.61 | mm |
| Distance outer ring from side face to snap ring groove | C | 2.06 | mm |
| chamfer dimension | rmin | min.1 |
| Manufacturer | Part Number |
|---|---|
| FAG | 6007N (FAG) |
