| activation | pneumatically | ||
| compressed air connection output | base plate iso 5599-1 | ||
| working pressure min. | -0.95 bar | ||
| Sealing principle | soft seal | ||
| valve type | spool valve | ||
| can be assembled into blocks | can be assembled into blocks | ||
| control pressure min. | 1.5 bar | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -20 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| compressed air connection input | base plate iso 5599-1 | ||
| mounting screw | with hexagon socket |
| nominal flow qn | 1400 l/min | ||
| connection type | plate connection | ||
| working pressure max | 16 bar | ||
| Standards | iso 5599-1 | ||
| Version | iso 1 | ||
| blocking principle | single base plate principle | ||
| control pressure max. | 16 bar | ||
| max. ambient temperature | 70 °c | ||
| max. medium temperature | 70 °c | ||
| max. particle size | 50 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| flow conductance c | 5.2 l/(s*bar) |
