| Medium | compressed air | ||
| min. medium temperature | -15 °c | ||
| min. ambient temperature | -15 °c | ||
| return | with spring return | ||
| valve type | poppet valve | ||
| Sealing principle | soft seal | ||
| electrical connection type | plug | ||
| voltage tolerance ac 60 hz | -10% / +15% | ||
| operational voltage ac at 60 hz | 110 v | ||
| working pressure max | 8 bar | ||
| compressed air connection output | Ø 8x1 | ||
| switching principle | 3/2 | ||
| activation | electrically |
| max. medium temperature | 50 °c | ||
| max. ambient temperature | 50 °c | ||
| blocking principle | single valve | ||
| connection type | pipe connection | ||
| pilot | internal | ||
| electrical connection size | iso 15217, form c | ||
| Manual override | with detent | ||
| voltage tolerance ac 50 hz | -10% / +15% | ||
| operational voltage ac at 50 hz | 110 v | ||
| working pressure min. | 2 bar | ||
| Version | nc | ||
| nominal flow qn | 850 l/min |
