| activation | pneumatically | ||
| compressed air connection output | base plate din iso 15407-1 | ||
| working pressure min. | -0.95 bar | ||
| Sealing principle | soft seal | ||
| certificates | free of substances that impair surface wetting in the coating process | ||
| valve type | spool valve, positive overlapping | ||
| control pressure min. | 3 bar | ||
| min. ambient temperature | -15 °c | ||
| min. medium temperature | -15 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| version pneumatic port | closed center | ||
| nominal flow qn 1 to 2 | 650 l/min |
| nominal flow qn | 650 l/min | ||
| connection type | plate connection | ||
| working pressure max | 16 bar | ||
| atex | suitable for atex | ||
| Standards | iso 15407-1 | ||
| Version | 26 mm | ||
| control pressure max. | 16 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 50 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| compressed air connection input | base plate din iso 15407-1 |
