| activation | electrically | ||
| switching principle | 3/2 | ||
| working pressure min. | 3.5 bar | ||
| Manual override | with detent | ||
| electrical connection size | form b, industry | ||
| basic valve with electrical connector | basic valve without coil | ||
| control pressure min. | 3.5 bar | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -20 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| compressed air connection input | g 1/4 | ||
| Weight | 0.38 kg |
| nominal flow qn | 1350 l/min | ||
| Version | no/nc | ||
| working pressure max | 10 bar | ||
| electrical connection type | plug | ||
| valve type | poppet valve | ||
| connection type | plate connection | ||
| control pressure max. | 10 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 5 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| Duty cycle | 100 % |
