FESTO 550619 manifold block

Name: 550619 FESTO
Brand: FESTO
SKU: 756376-en-gbp
Price: 36.94 GBP
Availability: SoldOut

CPE18-3/2-PRS-3/8-2-NPT

£36.94

Limited stock only available on quotation

Specifications

Operating Pressure	-0,9 bar ... 10 bar
Mounting Position	optional

Pneumatic connection	3/8 NPT
Weight	263.94g

Material manifold		Wrought aluminium alloy
Pneumatic connection, port 5		3/8 NPT
Pneumatic connection, port 1		3/8 NPT
Type of mounting in-line valve manifold		With through-hole
Max. tightening torque for valve mounting		2,034 Nm
Media temperature		-5 °C ... 50 °C
Operating pressure		-0,9 bar ... 10 bar
Max. number of pressure zones		2
Mounting position		optional

Note on materials		RoHS-compliant
Pneumatic connection, port 3		3/8 NPT
Mounting method for valve		Via female thread
Product weight		263,939 g
Ambient temperature		-5 °C ... 50 °C
Corrosion resistance class CRC		2 - Moderate corrosion stress
Burst pressure		725 psi
Max. number of valve positions		2
Grid dimension		26 mm
