| port 1 | Ø 8 | ||
| direction of throttle | 2 ▶ 1 | ||
| nominal flow qn 2 to 1 | 680 l/min | ||
| working pressure min. | 0.5 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Weight | 0.045 kg | ||
| seal material | acrylonitrile butadiene rubber |
| port 2 | Ø 8 | ||
| nominal flow qn 1 to 2 | 810 l/min | ||
| Medium | compressed air | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| Housing Material | polyamide |
