| fitting electronic interface | insertion 2 (inch) | ||
| product sub-group | fitting | ||
| diameter measuring tube (dn) | 32 mm | ||
| temperature medium max | 80 °c | ||
| nominal pressure (din en 1333) | pn 10 | ||
| armature material | pp (polypropylene with fibreglass) | ||
| port connection material category | plastics | ||
| port connection 1 dn inch | 1,25 inch2 | ||
| port connection 1 size dn | dn 25 | ||
| port connection 1 thread type | g | ||
| port connection 1 type | welded sleeve | ||
| max measured value of volume flow rate | 31.73 | ||
| fluidic port connection number | 2 | ||
| Customscode | 90269000 |
| installation length | 160 mm | ||
| Type | s020 | ||
| medium-contacting parts seal material | fkm (fluor rubber) | ||
| temperature medium min | 0 °c | ||
| measuring pipe material | pp (polypropylene with fibreglass) | ||
| port connection material | pp (polypropylene) | ||
| port connection 1 adhesive bonding | din 16962 | ||
| port connection 1 outer diameter (mm) | 40 mm | ||
| port connection 1 inner diameter (mm) | 32,2 mm | ||
| port connection 1 thread marking | 2 | ||
| measured value unit | l/h | ||
| min measured value of volume flow rate | 952 | ||
| Sensor type | for analytical sensor |
