| Part # | 32EFG3KX50INC / 32EFG3KX50INC | ||
| Minimum Bend Radius (in) | 12.50 | ||
| Hose Inside Diameter (in) | 2 | ||
| Temperature Range | -40°F to +250°F (-40°C to +121°C). For water emulsions see Temperature Limits Table. | ||
| Use | Spiral Wire | ||
| Reinforcement | Four alternating layers of spiraled, high-tensile steel wire. | ||
| Standard Industry Specification | EN 856 4SP, EN 856 R12, ISO 18752, ISO 3862 R12, SAE 100R12 | ||
| Weight (lbs.) | 3 | ||
| Product # | 46512209 |
| Continuous Operating Temperature Range | -40°F to +250°F | ||
| Min. Burst Pressure (psi) | 12,000 | ||
| Hose Outside Diameter (in) | 2.63 | ||
| Max. Working Pressure | 3,000 | ||
| Cover | Black, oil resistant, synthetic rubber (Polychloroprene - Type A), with color coded layline. Also available with unique abrasion resistant MegaTuff® cover. See Hose Stock Characteristics. | ||
| Tube | Black, oil-resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristics. | ||
| Notes | For Biodegradable Hydraulic Fluids. Meets Flame Resistance Acceptance Designation "MSHA 2G". | ||
| Packaging | S | ||
| UPC | 770075378044 |
