| protection type ip (max. with suitable connector) | ip65/67 | ||
| communication interface protocol | service-büs | ||
| Mounting type | namur / iec 534 - 6 / vdi/vde 3845 | ||
| Type | 8,792 | ||
| valve diameter | 2,2 mm | ||
| input 2 type digital transistor connection pnp | yes | ||
| input 1 type analog voltage | 0-5/10 v | ||
| temperature environment max | 60 °c | ||
| dc voltage | yes | ||
| voltage min / rated voltage | 24 v | ||
| port connection 3 thread type | g | ||
| port connection 3 type | inner thread | ||
| port connection 2 thread type | g | ||
| port connection 1 thread type | g | ||
| port connection 1 type | inner thread | ||
| pneumatic function 1 double acting | yes | ||
| for actuator size 175mm | yes | ||
| for actuator size 125mm | yes | ||
| displacement transducer type | internal rotative |
| control interface | keyboard and display internal | ||
| electrical connection sort | screw terminal with cable feed-through | ||
| product sub-group | positioner / process controller | ||
| function | positioner | ||
| qnn value (gas) | 100 l/min | ||
| input 1 type analog current | 0/4-20 ma | ||
| approval type | csa | ||
| temperature environment min | -10 °c | ||
| voltage max / rated voltage | 24 v | ||
| port connection 3 thread marking | 1/4 | ||
| port connection 3 pre-mounted | blind plug | ||
| port connection 2 thread marking | 1/4 | ||
| port connection 2 type | inner thread | ||
| port connection 1 thread marking | 1/4 | ||
| pneumatic function 1 single acting | yes | ||
| for actuator size 225mm | yes | ||
| for actuator size 130mm | yes | ||
| displacement transducer signal | potentiometer | ||
| Customscode | 90328900 |
