| electrical connection 1 gender | terminal block | ||
| electrical connection 1 number of contacts | 2 pce | ||
| Mounting type | direct installation | ||
| pwm frequency max. | 6.000 hz | ||
| generation | revision 2 | ||
| Type | 8,605 | ||
| input 1 type analog current | 0/4-20 ma | ||
| input 1 type analog voltage | 0-5/10 v | ||
| temperature environment max | 60 °c | ||
| maximum electrical power consumption | 1 w | ||
| dc voltage | yes | ||
| voltage tolerance positive | 10 % | ||
| voltage min / rated voltage | 12 v |
| electrical connection 2 number of contacts | 2 pce | ||
| electrical connection 1 type | cable feed-through | ||
| coil current max. | 1.000 ma | ||
| pwm frequency min. | 80 hz | ||
| product sub-group | valve electronics | ||
| input 1 type analogue current burden | 200 ohm | ||
| input 1 type analog voltage impedance | 20 kohm | ||
| coil current min. | 200 ma | ||
| temperature environment min | -10 °c | ||
| Residual ripple | 5 % | ||
| voltage tolerance negative | 10 % | ||
| voltage max / rated voltage | 24 v | ||
| Customscode | 85423111 |
