| Bore diameter | d | 40 | mm |
| Total bearing width | T | 19.75 | mm |
| Width Inner ring | B | 18 | mm |
| Corner radius inner ring | r1,2 | min.1.5 | |
| Distance pressure point | a | 16.05 | mm |
| Outside diameter | d2 | 80 | mm |
| Inner ring shoulder diameter | d1 | ≈57.55 | |
| Width Outer ring | C | 16 | mm |
| Corner radius outer ring | r3,4 | min.1.5 |
| Manufacturer | Part Number |
|---|---|
| FAG | 30208-XL (FAG) |
