| kv value (m*3/h) | 1,0 | ||
| medium temperature (degree c) (max) | 90 | ||
| pilot pressure (max.) | 6 | ||
| pressure (bar) (max) | 10 | ||
| port connection | g 3/8 threaded port | ||
| seal material | nbr | ||
| circuit function | 2/2-ways; normally closed | ||
| Customscode | 84818079 |
| ambient temperature (max) | 90 | ||
| medium temperature (degree c) (min) | -10 | ||
| pilot pressure (min.) | 3,3 | ||
| actuator | with reinforced spring | ||
| Material | brass | ||
| orifice size | 10mm (3/8") | ||
| typ | 262 |
