| protection type ip (max. with suitable connector) | ip65 | ||
| electrical cross-section leads (mm2) | 0,75 mm² | ||
| electrical connection wire diameter min | 5,5 mm | ||
| electrical connection wire length | 12.000 mm | ||
| cable plug without ciruit | yes | ||
| plug pattern | form a according to din en 175301-803 | ||
| Type | 2,513 | ||
| flat seal material | silicone | ||
| temperature environment min | -30 °c | ||
| ac voltage | yes | ||
| voltage min / rated voltage | 0 v |
| plug mounting screw | iron steel fusion-bonded passivated | ||
| electrical connection wire diameter max | 6,5 mm | ||
| electrical connection 1 wire material | pur (polyurethane) | ||
| electrical connection output direction | bottom | ||
| electrical connection number of contacts | 2 + 2 grounding conductor | ||
| product sub-group | cable plug | ||
| approval type | atex | ||
| temperature environment max | 90 °c | ||
| dc voltage | yes | ||
| voltage max / rated voltage | 250 v | ||
| Customscode | 85369010 |
