| hydraulic hose | hose, sktls/r6 | ||
| dash size | 12 | ||
| max temperature (c) | 100 | ||
| min temperature (c) | -40 | ||
| operating pressure (psi) | 250 | ||
| product line | aeroquip | ||
| agency listings: government specification | dnv, msha | ||
| burst pressure (bar) | 70 | ||
| description | low pressure socketless testile braid | ||
| general application | for gasoline, fuel and lubricating oils, air and water. not recommended for hydraulic impulse applications and not approved for airbrake applications. | ||
| Inside Diameter (in) | 0.75 | ||
| min bend radius (in) | 7 | ||
| Outside Diameter (in) | 1.03 | ||
| reinforcement material | textile braid reinforcement. | ||
| vacuum (kpa) | 61 | ||
| weight (lb/ft) | 0.25 |
| cover material | neoprene | ||
| hose family | socketless/r6 | ||
| max temperature (f) | 212 | ||
| min temperature (f) | -40 | ||
| operating pressure (bar) | 17 | ||
| tube material | nitrile | ||
| agency listings: industry specification | sae 30r2 type 1 | ||
| burst pressure (psi) | 1,000 | ||
| family | hose | ||
| hose base number | 2,556 | ||
| Inside Diameter (mm) | 19.10 | ||
| min bend radius (mm) | 177.80 | ||
| Outside Diameter (mm) | 26.20 | ||
| vacuum (inhg) | 18 | ||
| weight (kg/m) | 0.37 |
