| Weight | 0.33 kg/m, 0.22 lb/ft | ||
| hose inner tube material | polyoxymethylene | ||
| materials of construction | thermoplastic | ||
| minimum operating temperature | 14 °f, -10 °c | ||
| compatible fitting | lx series | ||
| design factor | 2.5:1 | ||
| hose outside diameter | 12.6 mm, 0.492 inch | ||
| maximum operating pressure | 23780 psi, 164 mpa, 1640 bar | ||
| product type | hydraulic hose, transfer hose, water blast hose, water hose | ||
| Application | industrial & marine cleaning, water jet cutting | ||
| division | polymer hose division europe | ||
| media | hydraulic fluids, mineral hydraulic oil, water | ||
| hose i.d. (mm) | 6.40 |
| hose reinforcement material | four spiral layers of maximum tensile steel wire | ||
| cover material | polyamide | ||
| specifications met | din en 1829-2 | ||
| maximum operating temperature | 70 °c, 158 °f | ||
| cover color | blue | ||
| minimum bend radius | 155 mm, 6.102 inch | ||
| hose inside diameter | 1/4 inch, 6.4 mm | ||
| product style | ultra-high pressure hose | ||
| technology | fluid & gas handling | ||
| industry | general industrial, marine | ||
| Brand | parker | ||
| maximum working pressure (mpa) | 164 | ||
| Cover | standard |
