| Bore diameter | d | 45 | mm |
| Width | B | 25 | mm |
| Shoulder/recess diameter of outer ring | D1 | ≈88 | |
| diameter of lubrication hole | S | 3 | mm |
| Outside diameter | d2 | 100 | mm |
| Shoulder diameter of inner ring | d2 | ≈65.3 | |
| Width of lubrication groove | b | 6 | mm |
| chamfer dimension | rmin | min.1.5 |
| Manufacturer | Part Number |
|---|---|
| FAG | 21309-E1-XL (FAG) |
