| CD | 30 | H9 | |
| D1 | 13.50 | mm | |
| EW | 90 | ||
| FL | 55 | ||
| DIN 912 | M16x50 | ||
| Tolerance for I | ± 0.5 | ||
| L1 | 7 | mm | |
| Tg | 140 |
| D | 65 | mm | |
| e | 180 | ||
| Tolerance for Ew | - 0.2 - 0.6 |
||
| Tolerance for FL | ± 0.2 | ||
| i | 10 | ||
| L | 35 | mm | |
| MR | 31 | ||
| Tolerance for TG | ± 0.3 |
| Fmax | Fmax EMC |
| m | 2.60 | kg |
