| min. ambient temperature | -10 °c | ||
| temporary ambient temperature (<30 s) min. | -30 °c | ||
| compressed air connection | m5 | ||
| Holding force | 2.3 n | ||
| max. curving on object rmin | 10 mm | ||
| hardness according to standard | 55 ± 5 shore a | ||
| Material connector | aluminum | ||
| delivery unit | 2 piece |
| max. ambient temperature | 70 °c | ||
| temporary ambient temperature (<30 s) max. | 120 °c | ||
| external diameter | 8 mm | ||
| Volume | 0.03 cm³ | ||
| abrasion value according to din 535 16 | 100-120 mm³ | ||
| connection thread type | external thread | ||
| suction unit material | acrylonitrile butadiene rubber | ||
| Weight | 0.0015 kg |
