FESTO 1400327 plug screw module

Name: 1400327 FESTO
Brand: FESTO
SKU: 835291-en-gbp
Price: 23.11 GBP
Availability: InStock

VTUG

£23.11

1 pcs. with 1 to 3 days delivery to United States

Specifications

Size	18 mm
Operating Pressure	-0,9 bar ... 10 bar

Actuation Type	Electric
Pneumatic connection	G1/8 G1/4 G3/8 QS-3 QS-4 QS-6 QS-8 QS-10 QS-12 QS-16 QS-1/4 QS-5/16 QS-3/8 QS-1/2

Max. number of valve positions		24
Electrical I/O system		no
Degree of protection		IP40 IP65 IP67 IP69K NEMA 4X
KC mark		KC-EMV
CE marking (see declaration of conformity)		To UK instructions for EMC To UK RoHS instructions
Exhaust-air function		With flow control option
Sealing principle		Soft
Type of piloting		Pilot actuated
Valve terminal structure		Fixed grid
Operating pressure for valve terminal with internal pilot air supply		1,5 bar ... 8 bar
Suitability for vacuum		yes
Nominal operating voltage DC		24 V
Permissible voltage fluctuations		+/- 10 % +/- 25%
Note on operating and pilot medium		Lubricated operation possible (in which case lubricated operation will always be required)
Shock resistance		Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Storage temperature		-10 °C ... 60 °C
Pilot medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Note on materials		RoHS-compliant
Valve function		2x3/2-way, monostable, closed 2x3/2-way, open, monostable 2x3/2-way, open/closed, monostable 3/2-way, closed, monostable 3/2 open, single solenoid 5/2 double solenoid 5/2-way, monostable 5/3-way, pressurised 5/3 exhausted 5/3 closed
Max. standard nominal flow rate		330 l/min at 10 mm 630 l/min at 14 mm 1200 l/min at 18 mm
Operating pressure		-0,9 bar ... 10 bar

Max. number of pressure zones		13
Ambient temperature		-5 °C ... 60 °C
Approval		RCM trademark c UL us - Recognized (OL)
CE mark (see declaration of conformity)		To EU EMC Directive In accordance with EU RoHS Directive
Certificate issuing authority		UL MH19482
Type of actuation		Electric
Design		Piston gate valve
Pilot air supply		External Internal
Signal status display		LED
Pilot pressure		1,5 bar ... 8 bar
Nominal pick-up current per solenoid coil		47 mA up to 20 ms
Nominal current with current reduction		15.5 mA after 20 ms
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Vibration resistance		Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Corrosion resistance class CRC		2 - Moderate corrosion stress
Media temperature		-5 °C ... 60 °C
Pilot air port 12/14		G1/8
Material seals		HNBR NBR
Valve size		18 mm
Standard nominal flow rate		130 l/min ... 1.150 l/min
Electrical control		Individual connection Fieldbus Multi-pin plug IO-Link® I-Port AP interface
