| Packaging | R | ||
| Recommended For | High-temperature medium-pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 Type AT. | ||
| Standard Industry Specification | SAE 100R1 AT | ||
| Reinforcement | One braid of high-tensile steel wire. | ||
| Use | Wire Braid | ||
| Hose Outside Diameter (in) | 1.10 | ||
| Min. Burst Pressure (psi) | 5,000 | ||
| Continuous Operating Temperature Range | -40°F to +275°F | ||
| Product # | 46572536 |
| Weight (lbs.) | 0.44 | ||
| Notes | Meets Flame Resistance Acceptance Designation "MSHA 2G". | ||
| Tube | Black, oil-resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristics. | ||
| Cover | Black, oil and abrasion resistant, synthetic rubber (CSM - Type M). | ||
| Temperature Range | -40°F to +275°F (-40°C to +135°C) constant and +300°F (+149°C) intermittent (up to 10% of operating time). For water emulsions see Temperature Limits Table. | ||
| Hose Inside Diameter (in) | 0.75 | ||
| Minimum Bend Radius (in) | 9.50 | ||
| UPC | 072053841794 | ||
| Part # | 12G1HXBALE / 12G1HXBALE |
