| pumps | pvm057er09gs02aaa2800000 1a0a | ||
| displacement | 057 : 57,4 cm3/r [3.50 in3/r] (315 bar max) | ||
| input rotation | r : clockwise (right hand) | ||
| Mounting flange | g : sae j744-127-4 (c, 4-bolt) (models 057, 074, 098 and 131) | ||
| port options | 02 : sae j518 flange ports, sae auxiliary ports | ||
| control | a : pressure compensator | ||
| flow comp setting / unload vlv standby | 00 : none | ||
| compensator special feature | 0 : none | ||
| paint | a : blue | ||
| design code | a : a |
| code title | pvm : vickers variable displacement open circuit piston pumps | ||
| valve plate | e : industrial (1800 r/min max) | ||
| input shaft | 09 : sae j744-32-1, sae c, straight keyed (model 057, 074, 098 and 131) | ||
| main port location | s : side | ||
| pump special features | aa : adjustable max displacement stop (contains single shaft seal) | ||
| pressure comp setting | 28 : 276-284 bar [4002-4118 lbf/in2] | ||
| other compensation / unload vlv reset | 00 : none | ||
| auxiliary mounting | 1 : auxiliary mount with cover plate, suitable for all thru-drive mounting kits | ||
| customer identification | 0 : none |
