| Port Connection (inch) | Internal Threaded (G1/2) | ||
| Nominal Volume (l) | 0.32 | ||
| Gas Volume (l) | 0.32 | ||
| Product Type | ELM 0.32-210/00/AF | ||
| Maximum Operating Pressure | 210 bar | ||
| Valve Port Size | Standard (Nitrogen rechargable) M28 x 1.5 inch | ||
| Weight | 1.4 kg | ||
| Diameter | 92 mm |
| Maximum Operating Pressure (bar) | 210 | ||
| Body Material | Carbon Steel | ||
| Product Series | ELM | ||
| Gas Volume | 0.32 L | ||
| Specifications Met | From 07/2016 PED97/23/EC Article 3.3 becomes PED2014/68/EU Article 4.3 | ||
| Elastomer | NBR nitrile standard rubber | ||
| Height | 135 mm | ||
| Industry | Mobile - Agricultural/Construction Equipment |
