| Application | industrial machinery, compressed air, robotics, mechanical constraints, cooling, welding, cabling | ||
| maximum operating pressure | 14.0 barg | ||
| minimum operating temperature | -20.0 °c | ||
| maximum operating temperature | 70.0 °c | ||
| vacuum pressure rating | 755.0 mm-hg | ||
| Color | green | ||
| tube i.d. (mm) | 12 | ||
| tube o.d. (mm) | 8 |
| specifications met | ul94 v-0 (fire resistance), di: 2002/95/ec (rohs), 2011/65/ec, rg: 1907/2006 (reach) | ||
| bend radius | 35.0 mm | ||
| media | industrial fluids, compressed air, coolants | ||
| number of tubes | 1 | ||
| Weight | 2085.0 kg/package | ||
| tubing material | puer - ul94 | ||
| Length (m) | 25 |
