| specifications met | industrial: di: 2002/95/ec (rohs), 2011/65/ec, di: 97/23/ec (ped), rg: 1907/2006 (reach)/food (pu ether food-grade "crystal"): fda: 21 cfr 177.2600, 178.3297, 176.170, 178.2010, rg: 1935/2004 ec | ||
| Application | food process, robotics, cabling, pneumatics, automation, in-plant automotive, rapid cycles | ||
| bend radius | 20 mm | ||
| vacuum pressure rating | 755 mm-hg | ||
| minimum operating temperature | -20 °c | ||
| weight (per unit of measure) | 0.03236 kg/m | ||
| Color | green crystal | ||
| tube o.d. (mm) | 8 |
| media | compressed air, industrial fluids (depending on the material type) | ||
| number of tubes | 1 | ||
| Weight | 1 kg/package | ||
| maximum operating temperature | 70 °c | ||
| maximum operating pressure | 12 barg | ||
| tube i.d. (mm) | 5, 5 | ||
| Length (m) | 25 | ||
| tubing material | puer |
