| material filter insert | impregnated paper | ||
| seal material | acrylonitrile butadiene rubber | ||
| Housing Material | die cast zinc | ||
| mounting orientation | vertical | ||
| recommended pre-filtering | 5 µm | ||
| filter reservoir volume | 150 cm³ | ||
| Medium | compressed air, neutral gases | ||
| min. ambient temperature | -10 °c | ||
| working pressure min. | 1.5 bar | ||
| nominal flow qn | 1600 l/min | ||
| port | g 1 | ||
| parts | pre-filter |
| material reservoir | die cast zinc | ||
| material front plate | acrylonitrile butadiene styrene | ||
| Type | can be assembled into blocks | ||
| Weight | 1.97 kg | ||
| filter element | exchangeable | ||
| max. achievable compressed air class acc. to iso 8573-1:2010 | 2 : - : 3 | ||
| max. ambient temperature | 60 °c | ||
| working pressure max | 16 bar | ||
| Condensate drain | fully automatic, open without pressure | ||
| filter porosity | 0.3 µm | ||
| reservoir | metal reservoir without window |
