| port 1 | Ø 6x1 | ||
| throttle bore Ø | 6.6 mm | ||
| nominal flow qn 2 to 1 | 900 l/min | ||
| compressed air connection type 2 | external thread | ||
| Medium | compressed air | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 70 °c | ||
| max. medium temperature | 70 °c | ||
| material flow control screw | brass |
| port 2 | g 3/8 | ||
| direction of throttle | 2 > 1 | ||
| compressed air connection type 1 | plug-in with tube nut | ||
| throttle | exhaust air throttling | ||
| working pressure min. | 0.5 bar | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c | ||
| Housing Material | aluminum, anodized | ||
| seal material | acrylonitrile butadiene rubber |
