| activation | pneumatically | ||
| switching principle | 5/2 | ||
| compressed air connection output | g 1/8 | ||
| working pressure min. | 3 bar | ||
| Sealing principle | soft seal | ||
| pilot | external | ||
| control pressure min. | 3 bar | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| compressed air connection, exhaust | g 1/8 | ||
| flow conductance b | 0.36 |
| nominal flow qn | 800 l/min | ||
| return type | with spring/air spring return | ||
| connection type | plate connection, pipe connection | ||
| working pressure max | 10 bar | ||
| valve type | spool valve, positive overlapping | ||
| blocking principle | plate principle | ||
| control pressure max. | 10 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 5 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| compressed air connection pilot exhaust | m5 |
