FESTO SRBC
21 Products
Discover all the available configurations for the FESTO SRBC product series Limit switch attachment. Find the right product by filtering with Mechanical interface, Sensor principle, Nominal operating voltage, Electrical output 1, Electrical connection, Cable connector and EU certification.
SRBC Type Codes
| Series | Catalog Number Format | Description |
|---|---|---|
| SRBC | SRBC-C- -YR-90- - - - | Limit switch attachment |
Typecode for Catalog Number SRBC,
SRBC-C- -YR-90- - - -
| 001 | Series |
|---|---|
| SRBC | Limit switch attachment |
| 002 | Design type |
| C | Sensor box |
| 003 | Mechanical interface |
| A3 | Mounting bridge, hole pattern 30 x 80 mm, shaft height 20 mm |
| A4 | Flexible mounting adapter |
| A5 | EN ISO 5211 / F05 |
| 004 | Display type |
| YR | Position indicator yellow/red |
| 005 | Measuring range |
| 90 | 0 ... 90° |
| 006 | Sensor principle |
| MW | Floating contact, changeover contact |
| N | Proximity sensor, inductive |
| R | With contacts (reed) |
| 007 | Nominal operating voltage |
| 1 | 24 V DC |
| 2A | 110 V AC/50-60 Hz |
| 20N | 8.2 V DC (Namur) |
| 22A | 250 V AC |
| 008 | Electrical output 1 |
|---|---|
| N | NPN |
| P | PNP |
| 1W | 1-pin toggle switch |
| 1WG | 1-pole changeover switch (gold contact) |
| ZC | 2-wire N/C contact |
| ZU | 2-wire N/O contact |
| 009 | Electrical connection |
| C2 | Screw terminal |
| M12 | Plug M12, A-coded |
| 010 | Cable connector |
| Without | |
| P20 | M20x1.5, polymer |
| 011 | EU certification |
| None | |
| EX6 | II 1GD |
