FESTO SME
45 Products
Discover all the available configurations for the FESTO SME product series Proximity sensor. Find the right product by filtering with Design type, Electrical connection, cable length, outlet orientation of connection, Switching output, Rated operating voltage, Cable characteristic, Cable length [m] and Connection technology.
SME Type Codes
| Series | Catalog Number Format | Description |
|---|---|---|
| SME | SME-10-M- -24- -L- - | Proximity sensor |
| SME | SME-8-- -K- -OE | Proximity sensor |
| SME | SME-8-M- - - - | Proximity sensor |
| SME | SME-10- -LED-24 | Proximity sensor |
Typecode for Catalog Number SME,
SME-10-M- -24- -L- -
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 10 | For round slot |
| 003 | Sensor version |
| M | Inserted in the slot from above |
| 004 | Switching output |
| DS | 3-wire N/O contact |
| ZS | 2-wire PNP N/O contact |
| 005 | Rated operating voltage |
| 24 | 24 V DC |
| 006 | Cable characteristic |
| None | |
| E | Suitable for energy chains/robot applications |
| 007 | Cable length [m] |
| ... | 0.2 ... 10 m |
| 008 | Display |
|---|---|
| L | LED |
| 009 | Cable outlet |
| Q | Transverse |
| L | Longitudinal |
| 010 | Cable identification |
| With label holder | |
| N | Without label holder |
| 011 | Connection technology |
| OE | Open end |
| M8 | M8, snap-on fl ange |
| M8D | M8, rotatable thread |
| M12 | M12, rotatable thread |
Typecode for Catalog Number SME,
SME-8-- -K- -OE
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 8 | For T-slot |
| 003 | Sensor version |
| Inserted in the slot lengthwise | |
| 004 | Switching output |
| None | |
| O | N/C contact, 3-wire |
| ZS | 2-wire PNP N/O contact |
| 005 | Switching status indication |
| None |
| LED | Yellow LED |
| 006 | Rated operating voltage |
|---|---|
| 24 | 24 V DC |
| 230 | 230 V AC |
| 007 | Cable characteristic |
| K | Standard/suitable for energy chains |
| 008 | Cable length [m] |
| 5,0 | 5.0 m |
| 7,5 | 7.5 m |
| 009 | Electrical connection |
| OE | Open end |
Typecode for Catalog Number SME,
SME-8-M- - - -
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 8 | For T-slot |
| 003 | Sensor version |
| M | Inserted in the slot from above |
| 004 | Switching output |
| DO | 3-wire N/C contact |
| DS | 3-wire N/O contact |
| ZS | 2-wire PNP N/O contact |
| 005 | Rated operating voltage |
| None |
| 24V | 24 V |
| 006 | Cable characteristic |
|---|---|
| E | Suitable for energy chains/robot applications |
| K | Standard/suitable for energy chains |
| 007 | Cable length [m] |
| ... | 0.2 ... 10 m |
| 008 | Connection technology |
| OE | Open end |
| M8 | M8, snap-on fl ange |
| M8D | M8, rotatable thread |
| M12 | M12, rotatable thread |
Typecode for Catalog Number SME,
SME-10- -LED-24
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 10 | For round slot, insertable in the slot lengthwise |
| 003 | Electrical connection, cable length, outlet orientation of connection |
| KL | Cable, 2.5 m, in-line |
| KQ | Cable, 2.5 m, lateral |
| SL | Plug M8x1 with cable, 0.3 m, in-line |
| SQ | Plug M8x1 with cable, 0.3 m, lateral |
| 004 | Switching status indication |
|---|---|
| LED | Yellow LED |
| 005 | Rated operating voltage |
| 24 | 24 V DC |
